MKD112B-024-GG1-AN
Bosch Rexroth Indramat
MKD112B-024-GG1-AN
Bosch Rexroth Indramat
![MKD112B-024-GG1-AN Image 1](https://distcache.org//images/large/mkd112b-024-gg1-an.jpg)
Description
The MKD112B-024-GG1-AN is a synchronous servo motor in the MKD Series Motors by Bosch Rexroth Indramat. Characterized by its plain shaft with a sealing ring, resolver feedback, and an electrically-released holding brake, this high-precision motor is designed for use in a wide range of industrial automation applications. The motor operates with a maximum current rating of 98.5 Amps and maintains a mass of 34 kg. Ideal for environments with an ambient temperature of 40 degrees C and a winding temperature of 155 degrees C, it ensures sustained performance with a maximum torque of 102 Nm. The MKD112B-024-GG1-AN supports a nominal speed of 2000 revolutions per minute, with a voltage constant of 130 Volts per 1000 revolutions per minute at 20 degrees C. Its protection degree is IP 65, indicating a high level of resistance to dust and water jets. The servo motor offers an installation altitude of up to 1000 m above sea level, with plug-in connector electrical connections for easy integration. The motor operates effectively within an environmental temperature range of 0 – 45 degrees C and includes a thermal time constant of 90 minutes. It also features a winding inductance value of 8.2 mH, a torque constant of 1.43 Nm/A at 20 degrees C, and a rotor motor inertia of 0.0192 kgm2. MKD112B-024-GG1-AN's current at standstill cooling mode is 21.9 A under natural convection scenarios, and 32.9 Nm under surface cooled scenarios. This motor is suitable for transportation and storage at temperatures ranging from -20 to 80 degrees C.
MKD112B-024-GG1-AN by Rexroth, Indramat, Bosch is a Digital AC Synchronous Servo Motor in the MKD Series. The MKD112B-024-GG1-AN features a Resolver Motor Feedback system and is Driven by a plain shaft (with shaft sealing ring). This Servo Motor has a Windings Code of 24 and comes with holding brake 22 Nms.
Revision Part #:
MKD 112B 024 GG1 ANMKD 112B-024-GG1-ANMKD-112B-024-GG1-ANMKD112B-O24-GG1-ANMKD112B024GG1ANManufacturer | Bosch Rexroth Indramat |
---|---|
Product Type | Digital Servo Motor |
Model | MKD112B-024-GG1-AN |
Feedback System | Resolver |
Moment of Inertia | 0.0192 kgm2 |
Protection Degree | IP 65 |
Nominal Speed | 2000 revolutions per minute |
Max. Torque | 102 Nm |
Max. Current Rating | 98.5 Amps |
Motor Weight | 34 kg |
